Fisher™ FIELDVUE™ DVC7K Digital Valve Controller
Quickly Troubleshoot and Take Action
FIELDVUE™ DVC7K DIGITAL VALVE CONTROLLER FEATURES

Quickly Troubleshoot and Take Action

The FIELDVUE™ DVC7K streamlines troubleshooting by identifying issues and recommending actions directly from the device, minimizing downtime and improving efficiency.

  • Reliable By Design: Built on 30 years of FIELDVUE hardware expertise, with 10 billion hours of run-time and over 3 million units sold, our technology delivers the same time-tested, service-proven core innovations you trust.
  • Real-Time Data Analysis: Harness the power of edge computing to analyze data in real time. The DVC7K provides 24/7 diagnostics with a larger internal memory, ensuring uninterrupted monitoring and comprehensive alert history retention for informed decision-making.
  • User-Friendly Interface: Monitor device health remotely using the intuitive LED indicator and Local User Interface (LUI). With Guided Setup, device configuration is fast and easy. Plus, customize the LUI to support up to 13 languages for global usability.
  • Seamless Connectivity: As a registered HART® communicating device, the DVC7K allows access to alerts, health status, and recommended actions at the device or anywhere along the loop. Gain deeper insights into your valve fleet with the Plantweb Insight Valve Health application for enhanced performance monitoring.
×
Want to Speak to an Expert?
Let us Answer Your Questions

Want to Speak to an Expert?

Mikas Kuprenas
Application Engineering Manager Flow
Final Control | Flow Controls

CONTACT MIKAS

Benefits and Features

SAFETY
  • Built for severe environments
  • Weathertight and easily mounted on valve bodies, or further away as needed
  • Safe to use in environments with flammable vapors
RELIABILITY
  • High-performing and linkage-less feedback system eliminates physical contact
  • Field proven, conformal coated electronics resist the effects of vibration, temperature, and corrosive atmospheres
OPERATOR-FRIENDLY
  • Monitor device health remotely with the LED and the Local User Interface (LUI)
  • The LUI supports 13 different languages
  • One Position Transmitter and two solid state dry contact switches can be used simultaneously
The Fisher FIELDVUE DVC7K instrument provides Advice at the Device™ via flexible connectivity; easy-to-use interface; and allows you to analyze data in real-time to evaluate performance and reliability enabling your operation to run closer to setpoint, improving product quality with more accurate control.

Fisher™ FIELDVUE™ DVC7K: Built to Withstand Challenging, Real-World Environments

Play Video
Fisher™ FIELDVUE™ DVC7K Digital Valve Controller

Specs

Area Classification
Intrinsically Safe, Explosion-proof, Dust-Ignition-proof, Increased Safety, Class/Div/Zone
Certifications
CSA, ATEX, IECEx, CML, CUTR, ECAS, INMETRO, KTL, CCC, NEPSI, PESO, SANS, UKEx
Communication Protocol
HART7
Data Interface
Wired
Diagnostics
Yes
Input Signal
4-20 mA DC, 24 VDC
Max Outlet Pressure
145 psig
Mounting Type
Integral Mounted
Operating Temperature
Standard Temperature, Extreme Temperature
Other Configurations
Contact your local Emerson sales office to learn about additional specifications or options for this product.
Position Control
Throttling Control, On/Off
Process Control
Flow, Pressure, Temperature, Level
Supply Media
Air or Natural Gas

Features

  • The high performance, linkage-less feedback system eliminates physical contact, which eliminates wearing on parts, maximizing cycle life.
  • The field proven conformal coated electronics resist the effects of vibration, temperature, and corrosive atmospheres.
  • Identify the health status of the valve assembly at a distance with the NE 107 LED indicator.
  • Easy-to-use interface provides visual instrument health identification, configuration and troubleshooting locally via Local User Interface (LUI).
  • Provides quick responsiveness to large step changes and precise control for small setpoint changes.
  • The self-diagnostic capability of the DVC7K provides valve performance and health evaluation without shutting down the process.
  • The modular design allows critical working components to be replaced without removing field wiring or pneumatic tubing.
  • When installed in an integrated control system, significant hardware and installation cost savings can be achieved.
  • Emerson's secure Bluetooth® wireless technology implementation enables ability to see health across multiple valves.
